In the demonstration, we have used DC Fan and DC Bulb. To drive this DC Fan and Light, a 9V battery is connected. Moreover, set the value of the pins connected with the three bulbs to HIGH by using digitalWrite() function. Specify the pin as the first parameter and the value as the second parameter. This will ensure that all the bulbs are off initially. Next, we declare the Arduino pins that are connected with the LCD.
Speech Controlled Device controlling can be further upgraded using the Internet of Things – i.e. This system can be further modified so that users can vary the speed of the Fan. It can even be modified to control the buzzer volume. However, other microcontrollers like 89s51, 89c51, 89s52, 89v51RD2, PIC18F4550, AVR ATmega32 can also be used. Home automation and Device controlling can be done using Internet of Things – IOT technology. The list of components mentioned here is specifically for controlling 4 different loads.
Home automation using Arduino and Bluetooth
Electroduino Tutorials help electronics lovers, makers, hobbyists, and engineers to learn and build electronics projects. We provide complete insight and technical details about electronic components and project tutorials and guides to implement projects. This blog is based on Home Automation using Arduino and Bluetooth HC-05 Module.
Then, the Arduino compares the value with the predefined value of the button. If this value is matching then Arduino sends operating voltage to the relay module. After complete the App setup/configuration, now we need to identify the load values of the App button. The app transmits Different load values when different buttons are pressed. When we will press a button on the app, the app sends a particular Load value to the Arduino through the Bluetooth module.
Connection Diagram of Bluetooth Controlled Home Automation Project
To define connections, we use the following line of code. This line creates a LiquidCrystal object and lcd is a name of the object that we are going to use to call LCD functions. The pin configuration of the PIR sensor is shown in the figure. PIR sensor consists of three pins, ground, signal, and power at the side or bottom. Generally, the PIR sensor power is up to 5V, but, the large size PIR modules operate a relay instead of direct output. This is a home automation project in which we can control electrical appliances using smartphones via Bluetooth.
Inside the infinite loop() we first check if serial data is available in the buffer. If data is found then the characters are added one by one to the array ‘inSerial’ using a while loop. Then we will call the Check_Protocol() function with ‘inSerial’ as an argument inside it. This function will be responsible for controlling the bulbs by comparing the received data and the command in the application. There are two types of pins on the whole 16×2 LCD module.
You are reading a preview.
Then the Arduino gets this value through the Bluetooth module. Then the Arduino sends Low input voltage to the Input-1 pin of the relay module. So the Device1 will also turn on, which is connected to the relay-1 of the relay module. At the same time, the “D1 is ON” status print on the 16×2 LCD Display Module. In the modern day’s everyone uses smartphones and the internet. Home Automation systems can make our life easy and secure.
Several remote controlled home automation systems have been studied. Arduino BT board was connected with home appliance and it was controlled by a Symbian OS cell phone application. Similarly, another study presented home automation system using Bluetooth and android application. However, this was designed only for 4 lights and it was not feasible to control more than 4 Home appliances. In another research work, XBee based home automation system introduced for handicapped and elderly people.
Share this document
You can make this application by yourself by using the MIT app inventor too. I hope you all will succeed to make this project by yourself you have to read and follow all the instructions given in the article. When we again Press the App “Button 1“, but this time the app sends Load value “A” to the Bluetooth module. Again the Arduino gets this value through the Bluetooth module. But this time the Arduino sends a High input voltage to the Input-1 pin of the relay module.
To develop a Bluetooth based home automation system with Arduino-UNO Board and an Android application. Remote controlled home automation system provides a simpler solution with Android application technology. Remote operation is achieved by any smart phone/Tablet etc., with Android OS, upon a GUI based touch screen operation. This project of speech-controlled home automation is for controlling any electronic appliances. For demonstration, a DC Fan and a DC Bulb have been used. A battery of 9 volts has been used as a power supply to the fan and the bulb.
Multiple devices/appliances can be controlled using one Android device. And we need to connect bulb, fan, buzzer to these relays. Similarly, when the user presses on the ‘On’ button displayed on the app for the device 2, the fan is switched on. The fan can be switched off, by pressing the same button again. You can follow our last Gsm-based home automation project which helped many students to make their projects. If you have any queries in the post you can ask us in the comment section.
Any person can use Voice Controlled Home Automation using Arduino project to control any electronic appliance in their home, shop, or industry. This can be done by an app on his/her Android Smartphone. We have interfaced the Arduino with the main circuit. The user can connect relays to various electronic home appliances. You can see in the block diagram below that Device 1 is Fan, Device 2 is Light and Device 3 is Buzzer.
Also, we create an array of 15 characters called inSerial that we will use later on in the code to monitor the states of the bulbs. The diagram shows the pin configuration of a 16×2 LCD display. We have a dedicated tutorial regarding interfacing 16×2 LCD display with Arduino with some example sketches. Have a look at it before proceeding further for a better understanding of the LCD.
Some pins are used to send to 16×2 LCD and some are command pins. In other words, every pin has a role in controlling a single pixel on the display.16 x 2 LCD has sixteen columns and two rows. That means, it can display sixteen characters per row and it has two such rows. DC motor is used to move a gearbox with a large reduction ratio. The final shaft imposes a force on the external load and simultaneously acts on the axis of the feedback potentiometer. So, the potentiometer senses the position of the axis and sends a corresponding voltage to an operational amplifier.
Similar to Bluetooth based home automation using Arduino UNO (
This Buzzer can be switched off, by pressing the same button again. After connected Bluetooth, your app screen will be like the above image now you can control the system, with the on and off button. Hey Guys, Welcome back to the Techatronic, we are Shahid and Adnan Electronics engineers making this awesome project for you. If you are looking for Home automation using Arduino and Bluetooth.
It is pretty simple You should have only the basic knowledge about electronics and microcontrollers. To make this Home automation using Arduino and Bluetooth Now you can make this project by the given step at our website. Open the application and connect to the Bluetooth module. Bluetooth module receives them and the Arduino performs the operation, displays the status on the LCD, and sends a message back to the mobile.
